ATX® Lat Pulldown with Weight Stack

ATX®
$2,395.00
Item No: ATX-LSW-750

3 in stock

paypal-seeklogo.com

DESCRIPTION

Weight 244 kg
Dimensions 230 × 54 × 47 cm
Weight

207 kg

Weight Capacity

160 kg

Height

220 cm

Certification

EN 20957 I.II.IV – S

Footprint

75×150 cm

The ATX Pin Loaded Lat Pulldown (ATX-LSW-750) is your commercial-grade beast, packing a 115kg weight stack and a tank-tough 70mm x 70mm steel frame into a compact 112.5cm footprint. This German-engineered legend delivers silky-smooth lat pulldowns, tricep pushdowns, and even ab crunches with a 1:1 weight ratio—no ego-padding mechanical advantage here.

Please note: The machine in the video is the plate loaded version which uses the same base as the Stack Weight version.

Why You Need This:

Pro-Grade Back Builder: 115kg stack and 1:1 ratio for heavy lat pulldowns, rows, and more, rivaling top gym machines.

Space-Saving Power: 112.5cm depth with a 60cm anti-slip footplate, squeezing commercial quality into home gyms.

Smooth & Durable: Double-bearing pulleys and industrial cables glide effortlessly, built for years of hardcore use.

Key Features:

115kg Weight Stack: 23 x 5kg plates with kg/lb markings, colour-coded for quick selection, no maxing out.

1:1 Weight Ratio: Lift exactly what you load (up to 115kg), with 155cm cable stretch for full lat activation.

Heavy-Duty Frame: 70mm x 70mm x 3mm steel with 7 x M12 bolts, certified for commercial use (EN 20957 Class S).

Silky-Smooth Action: Double-bearing pulleys, precision nylon bushings, and stretch-free cables for fluid reps.

Raised Seat & Footplate: 43cm seat height (vs. 38cm on older models) and 60cm anti-slip footplate for rows or kneeling pulldowns.

Included Extras: 2 x carabiners and an extension chain for versatile setups (lat bar, stirrup handle not included).

Overengineered Lat Pulldown Machine

ATX-LSW-750 compact lat pulldown machine


The most important feature of gym equipment is it’s strength, if you’re going to be pushing heavy weights you’re going to want to feel safe. The 70 x 70 x 3mm solid steel frame makes it more durable than a tank, meaning you can put your focus on your workout and stop worrying about your equipment failing.

It’s rare to find a free standing machine that doesn’t take up an entire room but still offers enough stability to use the whole stack safely. ATX® have done it all with this machine – it’s compact and space saving while remaining unbelievably strong.

The high pulley is perfect for lat pulldowns, tricep extensions and even ab crunches. The low pulley lets you perform the ultimate upper body exercise – bicep curls. And the large footrests make seated cable rows a dream. Let’s just say you’ll never be stuck for exercises. Taller users are hard pressed to find a lat machine that gives them enough space for full range of motion. But with 155cm between the seat and bar, this lat machine allows for even the tallest users to achieve full range of motion.

Sickness for the stiffness

ATX-LSW-750 bar holder

The top pulley housing has been completely redesigned. It is now manufactured out of 5 mm thick laser-cut steel sheets and is held together by a plethora of M12 bolts, so you can expect unyielding stability. Not doing any pulling? You can slot your bar into the V-cut located at the top of the machine

The old design featured 25 mm thick tube guiderails, which have been changed into 20 mm solid steel guiderails on the new model. ATX® have also gotten rid of the bolts in the guiderails and instead opted for Allen-screw bushings which make the assembly process just a tad easier.

ATX-LSW-750 reinforced pulley housing
ATX Lat Machine Upright Reinforcement Plates
5 mm thick Reinforcement Brackets

The main upright is manufactured out of 70 mm x 70 mm x 3 mm thick steel and is being held together by 2 x 5 mm thick solid steel sheets – which as you’ve guessed it have been laser cut. There are a total of 7 x M12 bolts holding the main upright together, so you will never have to worry about it losing its stiffness. The high and low pulley does not suffer from the mechanical advantage as it still features the same old 1:1 Ratio. Meaning the loaded weight will not be dimished due to excess pulleys. The ATX-LSW-750 cable machine comes with 115 kg weight stack which goes up in 5 kg increments.

Added inches to the right places

The seat height has been raised by a couple of inches compared to the older model (38 cm vs 43 cm), which is closer to the height of your regular bench. It may not seem like much, but you would be surprised how much difference a couple of inches can make.

ATX-LSW-750 adjustment knob
ATX-LSW-750 seat

Just because the German Engineers were craving for the extra does not mean that the tall people will not be able to get the full stretch. The ATX® Lat Pulldown Weight Stack features High-Stretch of 155 cm between the top pulley and the seat.

Stay comfortable while doing it seated

Training can get quite hard and intense so any added bit of comfort can go a long way. That’s why you will find angled, padded & adjustable knee rests which will help you lock yourself in during seated pulling exercises.

ATX-LSW-750 pu rollers
ATX-LSW-750 low pulley

Seated rows also have a bit of additional comfort as on the updated ATX-LSW-750 round tubes have been switched out for thick rubber footrests.

Thanks to the new continuous footplate there is nothing stopping you from getting down on your knees for some one arm lat pulldowns.

The 60 cm wide anti-slip footplate not only gives you a more secure base to train on, but also improves the overall stability of the machine. More importantly it reduces the footprint to just 112.5 cm (excluding the footprint) allowing you to squeeze it in the tightest places.

The Weight Stack

The 115kg weight stack is made up of 23 x 5kg plates, which provides more than enough weight for the exercises you’ll be doing with it. The weight stack features both kg and lb markings, which are handily colour coded so you can find your usual weight easier.

ATX-LSW-750 image from the back
ATX-LSW-750 115 kgs weight stack

You may think you have been pulling super heavy weights on other lat pulldown machines. But if you’re worried about maxing out the weight stack then you’ve got the wrong idea. The 1:1 weight ratio means you lift exactly the weight you load up. While you may have done 115kg lat pulldowns on other machines, I can almost guarantee you’re not going to do it on this machine.

The heavy duty double bearing pulleys are usually only seen in industrial applications and not gym equipment, but ATX® were looking to build a machine which will last through years of abuse. They allow for a smooth movement no matter how much weight is loaded and are fully prepared to cop abuse in a commercial environment.

What’s Included? ATX® Pin Loaded Lat Pulldown (ATX-LSW-750), 2 x Carabiners, Extension Chain.

Please note the pictures may feature optional attachments or items which are not included with the unit, this is to show the possible configurations/use of the unit.
